Twitter| Business Type | Manufacturer, Supplier |
| Size | 20 mm To 150mm |
| Number Of Way | 2way |
| Connection Type | Flanged |
| Click to view more | |
Preferred Buyer From
| Location | Anywhere in India |
Product Details
SIZE L (t±2) OD (±1mm) T (± 1mm ) PCD ( ±2mm) ØE ( t ±0.7mm) H (t ± 4mm)
25MM 159 120 18 79 14 111
40MM 185 140 18 98 14 132
50MM 214 165 19 122 18 146
65MM 241 180 22 140 18 176
80MM 257 203 22 152 18 181
100MM 300 230 24 191 18 213
BODY : ISOPP/PP/PPH/PVDF BALL : ISOPP/PP/PPH/PVDF
SPINDLE : EN8 INSURTED ISOPP/PP/PPH/PVDF SEAT : PTFE
FLANGE AND SPINDLE SEAL : EPDM/ PTFE/ VITON
HANDLE : MS WITH PVC SLEEVE FASTNER : SS304/SS316
HYDRO-TEST
PRESSURE 10 KG/CM2
TESTING MEDIUM : WATER AT AMBIENT TEMPERATURE
